Technical specification




N2G
Type 0.5


N2G
Type 1.0


N2G
Type 1.5


N2G
Type 2.5

N2G
Type 5.0

N2G
Type 10.5

DIMENSIONS (L x W x H)

208 x 88 x 211 mm

208 x 115 x 211 mm

208 x 143 x 211 mm

208 x 197 x 211 mm

434 x 273 x 235 mm 735 x 273 x 235 mm

WEIGHT

5.7 +/-5% 6.9 +/-5% 8.5 +/-5% 11.5 +/-5% 22.2 +/-5% 37.5 +/-5%

EXTINGUISHING AGENT

Nitrogen, IG -100 Nitrogen, IG -100 Nitrogen, IG -100 Nitrogen, IG -100 Nitrogen, IG -100 Nitrogen, IG -100

DISCHARGED IG-100 VOLUME

186 liters

371 liters

557 liters

928 liters

1857 liters 3899 liters

PROTECTED VOLUME

0.34 – 0.41 m3

0.68 – 0.82 m3

1.02 – 1.23 m3

1.71 – 2.05 m3

3.42 – 4.10 m3 7.06 –8.60 m3

GAS OUTPUT PRESSURE

3-5 bar

3-5 bar

3-5 bar

3-5 bar 3-5 bar 3-5 bar

ADR /UN

CLASS 9, UN 3268

CLASS 9, UN 3268

CLASS 9, UN 3268

CLASS UN-USED = 9, UN 3268
CLASS USED = 9, UN 3363 (Exempt)
CLASS 9, UN 3268 CLASS 9, UN 3268

HOUSING, TYPE AND INITIATION

Stainless steel box, electrical Stainless steel box, electrical Stainless steel box, electrical Stainless steel box, electrical Stainless steel box, electrical Stainless steel box, electrical

OPERATIONAL TEMPERATURE

-20 to +75 °C

-20 to +75 °C

-20 to +75 °C

-20 to +75 °C

-20 to +75 °C -20 to +75 °C

NITROGEN COMPOUND MASS

> 0.5 kg

> 1.0 kg

> 1.5 kg

> 2.5 kg

> 5.0 kg > 10.5 kg

EXTINGUISHING AGENT, Temperature

< 75 °C

< 75 °C

< 75 °C

< 75 °C

< 75 °C < 75 °C

DISCHARGE TIME

< 5 seconds

< 8 seconds

< 10 seconds

< 12 seconds

< 12 seconds < 14 seconds



N2G Generator safely eliminates fire, provides a timely and safe discharge, guaranties safe performance and non-life threatening O2 levels.

Generator Benefits

  • Equiped with a complex filter unit, discharges pure N2
  • Long shelf-life, no leaking threat, negligible inspection requirements
  • No clean-up of the precious goods or hardware after discharge
  • No damage to precious goods or hardware
  • No downtime of electrical current supply and ICT services provided
  • Clear, unobtrusive discharge facilitates ease of evacuation
  • No corrosive, acidic or toxic by-products from extinguishant decomposition
  • Extremely easy and fast to replace after discharge
  • Comparatively easy to monitor
  • Minimal maintenance and life-cycle costs
  • Can be equipped as stand-alone independent unit for fire detection and clean fire suppression with own fire/smoke/temperature sensors
  • Time-proven solutions, like the use of standard fire/smoke/temperature detection units and car airbag initiator devices
  • Compact system installation footprint that accommodates existing room, compartment structures and equipment as an ideal retrofit
  • Minimum installation, retrofit, maintenance time and costs, as a turn-key extinguishing solution for existing structures and applications
  • Any space/building can be retrofitted using the same fire detection sensors and releasing panel already installed – no pipework and/or additional electrical work needed

N2G GENERATOR Tests

N2G Generator Clean Discharge, 9 N-Heptane Can and Wooden Crib Tests by N2 Global Clean Agent Fire Suppression Systems.





EXTERNAL SOLUTION PRODUCTS

N2G is expanding production range. As for there are 6 types of standard generators for internal positioning (Type 0.5, Type 1.0, Type 1.5, Type 2.5, Type 5.0, Type 10.5), additionally 4 types of generators are currently available with external placement options:

- Type 0.5E,

- Type 1.0E,

- Type 1.5E,

- Type 2.5E.



LAUNCH SYSTEM

Sequential Activator

Early (smoke/temperature/CO2/SO2 etc.) detection + ASAS (Autonomous Sequential Activation System).

N2 GLOBAL has added its proprietary autonomous sequential activation system (ASAS) to the product line-up. Upon receiving the signal from two smoke/CO2/SO2/thermal/optical detectors, ASAS provides immediate seamless sequential activation of a necessary number of N2G generators of any type/size and/or placement form (internal/external). ASAS uses its own, in-built power source to provide signals to discharge the individual generators in a sequence with a 1 second interval. ASAS negates the necessity to employ fire control panel and/or sequential activators. We believe, both non-regulated and regulated electrical/control cabinet market will approve N2 GLOBAL’s highly dependable low-cost approach.

Manual Activator

N2 GLOBAL has added its proprietary autonomous manual activation device (AMAD) to the product line-up. Created specifically for military use, the AMAD is a part of N2 GLOBAL new N2G MD – “military design” derivative. AMAD provides instantaneous discharge and bears a (proven) reserve for 2000+ discharges or 2 year standby period. At a push of a button, 1.35A/10 ms signal initiates discharge.



MILITARY EDITION PRODUCTS

Manual Activator

N2 GLOBAL has added a Military Edition series to its product portfolio. The generators, even more robust, designed specifically to withstand extreme operation environments and most abusive handling, ready for any contingency, operate in conjunction with N2G autonomous manual activation device (AMAD), the latter providing instantaneous discharge and bearing a proven power reserve for 2000+ discharges or 2 year stand-by period. At a push of a button, 1.35A/10 ms signal initiates discharge. N2 GLOBAL Military Edition series come either in standard form or with an External Solution package, included.



TESTER

System Inspection Device (SID)

N2 GLOBAL has added its proprietary N2G fire protection system inspection device (SID) to the product line-up. Created purely for the needs of system integrator, system/network maintenance provider, SID allows to perform system check and verification within seconds. All system data is registered and preserved within devices memory for report purposes. N2 Global believes, the system maintenance time that SID saves will result in healthy profit of any distributor/system integrator/maintenance provider that elects to employ N2 GLOBAL fire suppression systems.
